HỘP CHIA & TỐI ƯU HÓA FTTH PON AN-WMT-FTTH-XX-YY-ZZ

Product Name

Wall Mount Fiber Splice Box

Feature

Wall mountable

Double or single door access

Keyway entry

Splice and termination

Up to 48 ports

Standard beige color

Locker feautured

Valdal proof

Fiber optical splitters and couplers are available in set with split ration from 1:2 to 1:64

Special price if ordered in set with AD-net GEPON active equipment systems o­nU’s and OLT’s

The sealing performance meets the IP65-level requirements of GB4208 standard, thus, it is suitable for outdoor distribution

Box body is made of metal materials, it looks nice in shape and its operation is convenient, anti-ageing and corrosion can be assured by the adoption of SMC compound materials

It is the combination of three functions: optical fusion, store and distribution

Adapter is installed with a certain angel, maintenance is easy, transmission loss is low

Specification

Max: Capacity: 48 Ports
Adapter type: ST/SC or any other o­n your request
Max number of splice trays: 5

 Weight:
1 door version: 5.2 kg
2 door version 6 kg

 Dimensions:
1 door version: 425x385x95mm
2 door version: 425X355X80mm

Ordering information

AN-WMT-FTTH-XX-YY-ZZ

XX – number of ports YY – Adapter type, FC, SC, or any other, or BLANK, if no any ZZ – Split ratio 1:2, 1:4 up to 1:64
