HC20WB4R2 - 4MP MOTORIZED FOCUS & ZOOM BULLET CAMERA

Model

HC20WB4R2

Video Standard

NTSC/PAL

Scanning System

Progressive

Image Sensor

1/3” CMOS

Number Of Pixels (H x V)

2560x1440

Minimum Illumination (Color/BW)

0.005 lux @F1.6, AGC o­n; 0 lux with IR

S/N Ratio

≥50db

Electronic Shutter Speed

1/2s ~ 1/100,000s

IR Distance

20 ~ 30 m

IR Light Control

Smart IR (Auto/Manual)/OFF

Day/Night

ICR

Backlight Compensation

WDR, HLC, BLC

White Balance

Auto/Indoor/Outdoor/Manual

Gain Control

Auto/Manual

Wide Dynamic Range

120dB

Noise Reduction

3D DNR

Lens

2.8~12mm@ F1.4

Angle Of View

H:92°~31°, V:48°~17.2°

Privacy Masking

Off / o­n (4 Areas)

Local Storage

Micro SD (up to 256 GB)

VIDEO

Video Compression

Main stream: H.265 / H.264
Sub stream: H.265 / H.264 / MJPEG
Third stream: H.265 / H.264 / MJPEG

Resolution

4MP (2560 × 1440), 3MP (2304 × 1296),
1080P (1920 × 1080), 720P (1280 × 720), D1,
480× 240, CIF

Number of Video Streams

3

Frame Rate Main Stream

60Hz: 4MP/3MP/1080P/720P(1~30fps);
50Hz: 4MP/3MP/1080P/720P(1~25fps)

Frame Rate Second Stream

60Hz: 720P/D1/CIF (1~30fps);
50Hz: 720P/D1/CIF (1~25fps)

Frame Rate Third Stream

60Hz: D1/480× 240/CIF (1~30fps);
50Hz: D1/480× 240/CIF(1~25fps)

Bit Rate

64 Kbps ~ 8 Mbps

Ingress Protection

IP67

Impact Resistance

IK10

AUDIO

Audio Compression

G.711A/G.711U

Audio Stream

1-way

Audio Interface

1CH audio input

NETWORK

Ethernet

10 Base-T/100 Base-TX Ethernet (RJ-45)

Supported Web Browsers

Chrome/Edge

Supported OS

Microsoft Windows 10

Protocols*

IPv4, IPv6, TCP / IP, UDP, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DNS, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPs, QoS, IGMP / Multicast, ICMP, ARP, TLS

Interoperability

ONVIF Profile G/S/T

Maximum Users Access

3 Users

Security

User account and password protection, HTTPS, IP Filter, Digest authentication, TLS1.2 o­nly, AES128/256, SSH / Telnet closed

Languages Supported

English, Italian, Portuguese, Russian, Spanish(Mexico), Dutch, French, German, Polish, Japanese, Chinese, Korean

EVENTS / ANALYTICS

Built-in Video Analytics

Motion Detection, Tampering, Intrusion, Object, Video Exception (scene change, video blur and video cast detection), line crossing detection and region intrusion detection

Region Of Interest

8

ELECTRICAL

Power Supply

12VDC, PoE (IEEE 802.3af) (Class 3)

Power Consumption (Max)

MAX 8W

MECHANICAL

Dimensions (D x D x H)

Ø 217.8 mm × 80.5 mm × 80.3 mm (Ø 8.57 x 3.16 x 3.16)

Product Weight

0.66 kg (1.45lb)

Package Weight

0.76 kg (1.67lb)

Body Material

Metal housing

ENVIRONMENTAL

Operating Temperature

-30 °C ~ 60 °C (-22°F~140°F)

Relative Humidity

Less than 90% (non-condensing)

REGULATORY

Emissions

EN 55032, FCC PART 15

Immunity

EN 55035

Safety

IEC 60950-1, IS 13252(Part 1)

RoHS

IEC 62321

SYSTEM COMPATIBILITY

20 Series NVR

Integration with 20 Series NVR

35 Series NVR

Integration with 35 Series NVR
